The FIORI DB 460 is a self-loading mixer with a 4 m³ concrete yield which offers operators excellent visibility and ergonomics with its reversible driver’s seat, four-wheel drive, four-wheel steering, with a tilting and swiveling drum system.
WEIGHT
| Operating Weight | 7,300 kg |
| Max Gross Weight | 16,500 kg |
| Load-carrying Capacity | 9,200 kg |
LOADER
| Volumetric Capacity | 560 L |
| Number of Loaderfuls per load | 9-10 Average |
MIXING AND UNLOADING
Double-cone drum with double-spiral mixing screws and a convex bottom
| Geometrical Drum Volume | 5,050 L |
| Drum Rotation Speed | 22 RPM |
| Class S1 Concrete Produced | 4 cubic meters |
WATER SYSTEM
| Max Capacity | 250 L / minute |
| Maximum Head | 4 Bar |
| Two Tanks (Polyethylene) Capacity | 870 L |
ELECTRIC SYSTEM
| Battery | 12 V – 135 Ah (850 A) |
